High-Speed Digital System Design

High-Speed Digital System Design bridges the gap from theory to implementation in the real world. Systems with clock speeds in low megahertz range qualify for high-speed. Proper design results in quality digital transmissions and lowers the chance for errors. This book is for computer and electrical engineers who may or may not have learned electromagnetic theory. The presentation style allows readers to quickly begin designing their own high-speed systems and diagnosing existing designs for errors. After studying this book, readers will be able to:

Design the power distribution system for a printed circuit board to minimize noise

Plan the layers of a PCB for signals, power, and ground to maximize signal quality and minimize noise

Include test structures in the printed circuit board to easily diagnose manufacturing mistakes

Choose the best PCB design parameters such a trace width, height,and routed path to ensure the most stable characteristic impedance

Determine the correct termination to minimize reflections

Predict the delay caused by a given PCB trace

Minimize driver power consumption using AC terminations

Compensate for discontinuities along a PCB trace

Use pre-emphasis and equalization techniques to counteract lossy transmission lines

Determine the amount of crosstalk between two traces

Diagnose existing PCBs to determine the sources of errors.
